X ray Machines

Zimed offer mobile and portable X-ray machines featuring high frequency inverter to emit good quality X-rays at minimal radiation doses. Give consistent and replicable radiation dose and features kV analog closed loop control, mAs digital closed loop control and micro processing real-time control radiography techniques.

compare product
  • Specification

    Power output 2.5 kW
    X-ray tube (Fixed anode focus) 1.5 mm
    mAs 1.0 to 160 mAs (45 steps)
    Inverter frequency 50 kHz
    Tube voltage 40 to 100 kV
    Battery
    Tube current 40 to 49 kV, 50 mA
    50 to 59 kV, 42 mA
    60 to 69 kV, 36 mA
    70 to 79 kV, 31 mA
    80 to 89 kV, 28 mA
    90 to 100 kV, 25 mA
    Operation mode Wire and wireless control
    Power supply 220 V ± 10 %
    50 Hz (R = ≤ 1.0 Ω)
    Display mode LCD
  • Features

    • 50 exposure preset values
      Two buttons to adjust kV and mAs vales
      Symmetrical beam applicator for field adjustment
      High quality X-ray minimizing excess radiation
      20 m microwave exposer remote control
compare product
  • Specification

    Power output 3.5 kW
    X-ray tube (Fixed anode focus) 1.5 mm
    mAs 1.0 to 125 mAs (43 steps)
    Inverter frequency 50 kHz
    Tube voltage 40 to 110 kV
    Battery
    Tube current 40 to 49 kV, 63 mA
    50 to 59 kV, 55 mA
    60 to 69 kV, 45 mA
    70 to 79 kV, 40 mA
    80 to 89 kV, 36 mA
    90 to 99 kV, 32 mA
    100 to 110 kV, 20 mA
    Operation mode Wire and wireless control
    Power supply 220 V ± 10 % ;
    50 Hz (R = ≤ 1.0 Ω)
    Display mode LCD
  • Features

    • 50 exposure preset values
      Two buttons to adjust kV and mAs vales
      Symmetrical beam applicator for field adjustment
      High quality X-ray minimizing excess radiation
      20 m microwave exposer remote control
compare product
  • Specification

    Power output 5 kW
    X-ray tube (Fixed anode focus) 1.5 mm
    mAs 1.0 to 180 mAs (46 steps)
    Inverter frequency 50 kHz
    Tube voltage 40 to 100 kV
    Battery
    Tube current 40 to 9 kV, 100 mA 50 to 59 kV, 77 mA
    60 to 69 kV, 64 mA
    70 to 79 kV, 55 mA
    80 to 89 kV, 49 mA
    90 to 99 kV, 44 mA
    100 to 109 kV, 32 mA
    110 to 120 kV, 25 mA
    Operation mode Wire and wireless control
    Power supply 220 V ± 10 % ;
    50 Hz (R = ≤ 1.0 Ω)
    Display mode LCD
  • Features

    • 50 exposure preset values
      Two buttons to adjust kV and mAs vales
      Symmetrical beam applicator for field adjustment
      High quality X-ray minimizing excess radiation
      20 m microwave exposer remote control
      Automatic calibration for center of gravity
compare product
  • Specification

    Power output 5 kW
    X-ray tube (Fixed anode focus) 1.5 mm
    mAs 1.0 to 180 mAs (46 steps)
    Inverter frequency 50 kHz
    Tube voltage 40 to 100 kV
    Battery Internalized battery
    Tube current 40 to 9 kV, 100 mA 50 to 59 kV, 77 mA
    60 to 69 kV, 64 mA
    70 to 79 kV, 55 mA
    80 to 89 kV, 49 mA
    90 to 99 kV, 44 mA
    100 to 109 kV, 32 mA
    110 to 120 kV, 25 mA
    Operation mode Wire and wireless control
    Power supply 220 V ± 10 % ;
    50 Hz (R = ≤ 1.0 Ω)
    Display mode LCD
  • Features

    • 50 exposure preset values
      Two buttons to adjust kV and mAs vales
      Symmetrical beam applicator for field adjustment
      High quality X-ray minimizing excess radiation
      20 m microwave exposer remote control
      Automatic calibration for center of gravity
      Internalized rechargeable battery supports 200 mA X-ray shots
compare product
  • Specification

    Output power 4 kW
    X-ray tube (Focus) 0.6 / 1.6 mm
    mAs (Adjustable) 1 to 190 mAs
    Tube voltage (Adjustable) 40 to 110 kV
    Nominal power 100 kV, 40 mA, 0.1 s, 4 kW
    mA (Adjustable) 36 to 60 mA
    Power supply 220 V ± 22V ; 50 to 60 Hz ± 1Hz
    Anode heat capacity
    (X-ray tube)
    76 kHU
    Machine frame size Highest : 1060 × 790 × 2210 mm
    Lowest : 1060 × 790 × 1240 mm
    Size 290 × 260 × 230 mm
    Weight 18.8 kg
  • Features

    • Flat panel digital detector (optional) of 17 × 17 inch
      Simulation and digital double loop control
      48 different preset anatomy memory choices
      High quality X-ray minimizes excess radiation
      Self-diagnosis
      Failure alert for self-protection
