Zimed Urine Analyzers are compact, portable, and essential in clinical diagnostics providing quick and reliable analysis of urine samples. We offer both single and continuous testing modes. Features error detection systems, control solutions, and automated calibration. Our analyzer offers a high throughput and speed gives exact results with minimal sampling. Built-in alarms and reminders for effective operation. We provide automated sample processing and multi-parameter testing for more accurate and user-friendly diagnostics.
Output: 514 strips/hrs.
Test mode: Single and continuous
Test principle: Photometry (dual wavelength)
Light source (wave length): Cold lamp (520, 640, 660 nm)
Output: 120 samples / hr
Wavelength: 558 nm, 635 nm, 720 nm
Operating temperature: 0 to 40 ° C
Relative humidity: < 85 %
Throughput: 100 strips / hr
Light source: LED
Wave length: 520 nm, 640 nm, 660 nm
Test mode: Manual and automatic
Test Parameters:
pH, Nitrite, Specific Gravity, Glucose, Protein, Blood, Bilirubin, Ketone, Leucocytes, Urobilinogen, Ascorbic Acid
Measurement Technology:
Dual-wavelength reflectance method (3 LEDs: 550nm, 620nm, 720nm)
Speed & Throughput:
60 sec/test
Normal mode:
60 tests/hour
Output: 30 to 60 sample/hr
Test mode: Fully-Automated
Test principle: Planar flow technology, SVM technology
Sample volume: 2 ml (non-centrifugal urine)
Urine Analyzer Capacity:
Number of Initial Samples: 100
Maximum Additional Samples: Up to 300
Urine Analyzer Throughput: 360 T/H
Urine Analyzer Test Principle: Photoelectric colorimetric principle, multiwavelength measurement determination.
Urine Analyzer Test Components:
UBG, BIL, KET, BLD, PRO, NIT, LEU, GLU, pH ( Standard)
SG, VC, MALB, CRE, Ca (Optional)
