Anesthesia Machine ZAM-A15 is equipped with a respiratory rate adjustable from 1 to 100 bpm for controlled ventilation. Its high-precision flowmeter provides instant monitoring of fresh gas flow. Featuring a vaporizer with temperature, pressure, and flow compensation alongside a self-lock function. Our Medical Anesthesia Equipment is an essential tool for delivering safe, efficient, and adaptable anesthesia care.
| Ventilation Mode | IPPV, A/C, SIMV, SIGH, MAUN |
| Gas Source | O₂, N₂O, AIR |
| Flowmeter Range | O₂: 0.1 to 10 L/min N₂O: 0.1 to 10 L/min AIR: 0.1 to 10 L/min |
| Rapid Oxygen Supply | 25 L/min to 75 L/min |
| Oxygen Concentration | 15% to 100% |
| Inspiratory-To- Expiratory Ratio (I:E) | 2:1 to 1:6 |
| Tidal Volume (VT) | 0ml to 2000ml |
| Minute Volume (MV) | 0 L/min to 100 L/min |
| Respiratory Rate (Freq) | 1bpm to 100bpm |
| Positive End-Expiratory Pressure (PEEP) | 0cmH₂O to 30cmH₂O |
| Pressure Control (PC) | 5cmH₂O to 60cmH₂O |
| Pressure Trigger (PTr) | -20 cmH₂O to 20 cmH₂O |
| Flow Trigger (FTr) | OFF, 0.5 L/min to 30 L/min |
| Inspiratory Time (Tinsp) | 0.2s to 6s |
| Inspiratory Pause (TIP) | 0s to 3s |
| Apnea Ventilation | OFF, 5s to 60s |
| SIGH | 0 (off) 1/100 to 5/100 |
| Gas Pressure | 280kPa to 600kPa |
| Bellow Volume | 1.5 L |
| Graphical Display | P-T (pressure – time) F-T (flow – time) |
| Alarms | AC Power Failure Alarm: Power failure or no connection Internal Battery Low Voltage: < 11.3 ±0.3V No Tidal Volume: ≤5mL within 6s High Oxygen Concentration: 19% to 100% Low Oxygen Concentration: 18% to 99% High Airway Pressure: 20cmH₂O to 100 cmH₂O Low Airway Pressure: 0 cmH₂O to 20 cmH₂O High Minute Volume: Adult (5L/min to 20L/min) Low Minute Volume: Pediatric (1L/min to 15L/min, 0 to 10L/min) Continuous Pressure: (PEEP + 1.5 kPa) over 16s Suffocation Warning: 5s to 60s no spontaneous ventilation Maximum Limited Pressure: ≤ 12.5 kPa |
| Error Indicators | Fan Error: Shown on screen Oxygen Deficit: Shown on screen |
| Display | 7"Colorful TFT LCD display screen |
| Power Consumption | 85VA |
| Power Supply | 100V to 240V, 50/60Hz |
| Packaging Dimensions | 760 × 970 × 1550 mm |
| Net Weight | 82.5 kg |
| Gross Weight | 143 kg |
7-inch color TFT LCD screen
real-time waveform display
Adjustable tidal volume
Flexible inspiratory-to-expiratory ratio
Rapid oxygen supply
Adjustable respiratory rate
Wide oxygen concentration range
Vaporizer with built-in safety features
Accessories | Quantity |
Anesthetic breathing system | 1pc |
CO₂ sensor | 1pc |
Anesthetic vaporizer | 2pcs |
Power cord (4m) | 1pc |
Fuse (250V) | 11pcs |
O₂ cell | 1pc |
Adult anesthesia breathing circuit (reusable) | 2pc |
Child anesthesia breathing circuit (reusable) | 2pc |
Breathing tube | 1pc |
Y connector (Adult) | 1pc |
Y connector (Children) | 1pc |
L connector | 2pc |
Straight connector | 1pc |
Reservoir bag 1L | 1pc |
Reservoir bag 3L | 1pc |
Anesthetic mask adult | 1pc |
Anesthetic mask infant | 1pc |
High pressure O₂ hose | 1pc |
High pressure air hose | 1pc |
High pressure N₂O hose | 1pc |
Auxiliary Common Gas Outlet (ACGO) | 1pc |
Drawers | 2pc |
Vaporizer | 2pc |
Spare Cylinder yoke, 1 O₂, includes gauges
Spare Cylinder yoke, 1 N₂O, includes gauges
Anesthetic gas scavenging system
Disposable adult breathing circuit
Disposable pediatric breathing circuit
Patient monitor
Our Anesthesia Machine ZAM-A15 is used in ICUs, operating rooms, and anesthesiology departments for precise respiratory management and anesthesia delivery in adult, pediatric, and infant patients.
Frequently Asked Question
The machine supports minute volumes from 0 L/min to 100 L/min, ensuring adequate ventilation for different patient sizes.
The respiratory rate can be set between 1 bpm to 100 bpm.
PEEP can be adjusted between 0 cmH₂O to 30 cmH₂O, helping maintain lung function.
Pressure Control (PC): 5 cmH₂O to 60 cmH₂O Pressure Trigger (PTr): -20 cmH₂O to 20 cmH₂O Flow Trigger (FTr): OFF, 0.5 L/min to 30 L/min
Errors are displayed on the screen, including: Fan Error Oxygen Deficit
The Zimed Anesthesia System is a medical device used to deliver anesthetic gases and oxygen to patients during surgery or medical procedures. It ensures the patient remains unconscious, pain-free, and stable throughout the operation.
Our machine delivers a controlled mixture of gases, which the patient inhales through a mask or endotracheal tube. The ventilator supports breathing, and the vaporizer ensures precise delivery of anesthetic agents. Sensors monitor vital signs and gas concentrations for safety.
Yes, our anesthesia machines can function as ICU ventilators, providing long-term mechanical ventilation support for critically ill patients when needed.
The scavenging system collects excess anesthetic gases and vents them safely outside the operating room. Proper ventilation and personal protective measures further reduce exposure risks.
