Electrosurgical Units

Zimed offer varied range of Electro-surgical Units used during monopolar and bipolar surgeries to remove unwanted or harmful tissue. Our products are fabricated for its precise destruction of tissues and control of blood clots during surgery. Our products are ISO and CE approved and certified.

Electrosurgical unit ZEU-A10
compare product

  • Specification

    Output Power 100 W
    Operating frequency ( monopolar ) 330 kHz/430 kHz
    Power Rating 500 VA ± 10 %
    Monopolar cut operation ( pure/ blend cut ) 0 to 100 W (300 Ω )
    Monopolar coagulation operation ( forced ) 0 to 80 W ( 500 Ω )
    Monopolar coagulation operation ( soft ) 0 to 40 W ( 500 Ω )
    Operating frequency ( bipolar )
    Bipolar coagulation
    Biopolar
    Monopolar cut ( load 500 Ω )
    Monopolar coagulation ( load 500 Ω )
    Bipolar (coagulation / AUTO ) ( load 100 Ω )
    Endoscopy
    Undewater Support

  • Features

    • Energy output up to 150 W
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Error alarm for failure detection system
      Easy to operate
Electrosurgical unit ZEU-A11
compare product

  • Specification

    Output Power 150 W
    Operating frequency ( monopolar ) 330 kHz/430 kHz
    Power Rating 500 VA ± 10 %
    Monopolar cut operation ( pure/ blend cut ) 0 to 150 W (300 Ω )
    Monopolar coagulation operation ( forced ) 0 to 80 W ( 500 Ω )
    Monopolar coagulation operation ( soft ) 0 to 40 W ( 500 Ω )
    Operating frequency ( bipolar )
    Bipolar coagulation
    Biopolar
    Monopolar cut ( load 500 Ω )
    Monopolar coagulation ( load 500 Ω )
    Bipolar (coagulation / AUTO ) ( load 100 Ω )
    Endoscopy
    Undewater Support

  • Features

    • Energy output up to 150 W
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Error alarm for failure detection system
      Easy to operate
Electrosurgical unit ZEU-A12
compare product

  • Specification

    Output Power 80 W
    Operating frequency ( monopolar ) 330 kHz/430 kHz
    Power Rating 300 VA ± 10 %
    Monopolar cut operation ( pure/ blend cut )
    Monopolar coagulation operation ( forced )
    Monopolar coagulation operation ( soft )
    Operating frequency ( bipolar ) 1000 kHz
    Bipolar coagulation 0 to 80 W ( 300 Ω )
    Biopolar 0 to 80 W ( 100 Ω )
    Monopolar cut ( load 500 Ω )
    Monopolar coagulation ( load 500 Ω )
    Bipolar (coagulation / AUTO ) ( load 100 Ω )
    Endoscopy
    Undewater Support

  • Features

    • Energy output up to 150 W
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Error alarm for failure detection system
      Easy to operate
Electrosurgical unit ZEU-A20
compare product

  • Specification

    Output Power 300 W
    Operating frequency ( monopolar ) Monopolar: 330 kHz / 430 kHz
    Bipolar : 1000 kHz
    Power Rating
    Monopolar cut operation ( pure/ blend cut )
    Monopolar coagulation operation ( forced )
    Monopolar coagulation operation ( soft )
    Operating frequency ( bipolar )
    Bipolar coagulation
    Biopolar
    Monopolar cut ( load 500 Ω ) Pure cut : 0 to 300 W
    Blend cut 1: 0 to 100 W
    Blend cut 2: 0 to 200 W
    Monopolar coagulation ( load 500 Ω ) Pure cut : 0 to 300 W
    Blend cut 1: 0 to 100 W
    Blend cut 2: 0 to 200 W
    Bipolar (coagulation / AUTO ) ( load 100 Ω ) 0 to 100 W
    Endoscopy Yes
    Undewater Support Yes

  • Features

    • Energy output ( 300 W )
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Built in system for under water cut
      Error alarm for failure detection system
      High level of surgical precision
Electrosurgical unit ZEU-A21
compare product

  • Specification

    Output Power 300 W
    Operating frequency ( monopolar ) Monopolar: 330 kHz / 430 kHz
    Bipolar : 1000 kHz
    Power Rating
    Monopolar cut operation ( pure/ blend cut )
    Monopolar coagulation operation ( forced )
    Monopolar coagulation operation ( soft )
    Operating frequency ( bipolar )
    Bipolar coagulation
    Biopolar
    Monopolar cut ( load 500 Ω ) Pure cut : 0 to 300 W
    Blend cut 1: 0 to 100 W
    Blend cut 2: 0 to 200 W
    Monopolar coagulation ( load 500 Ω ) General surgery : 0 to 120 W
    Forced coagulation : 0 to 100 W
    Soft coagulation : 0 to 50 W
    Bipolar (coagulation / AUTO ) ( load 100 Ω ) 0 to 100 W
    Endoscopy Yes
    Undewater Support

  • Features

    • Energy output ( 300 W )
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Built in system for under water cut
      Error alarm for failure detection system
      High level of surgical precision
Electrosurgical unit ZEU-A22
compare product

  • Specification

    Output Power 300 W
    Operating frequency ( monopolar ) Monopolar: 330 kHz / 430 kHz
    Bipolar : 1000 kHz
    Power Rating
    Monopolar cut operation ( pure/ blend cut )
    Monopolar coagulation operation ( forced )
    Monopolar coagulation operation ( soft )
    Operating frequency ( bipolar )
    Bipolar coagulation
    Biopolar
    Monopolar cut ( load 500 Ω ) Pure cut : 0 to 300 W
    Blend cut 1: 0 to 100 W
    Blend cut 2: 0 to 200 W
    Monopolar coagulation ( load 500 Ω ) General surgery : 0 to 120 W
    Forced coagulation : 0 to 100 W
    Soft coagulation : 0 to 50 W
    Bipolar (coagulation / AUTO ) ( load 100 Ω ) 0 to 100 W
    Endoscopy
    Undewater Support

  • Features

    • Energy output ( 300 W )
      Digital display for visualization of working parameters
      Push button for quick change of parameters
      Built in system for under water cut
      Error alarm for failure detection system
      High level of surgical precision
Electrosurgical Unit ZEU-A60
compare product

  • Specification

    Working mode (Monopolar)
    Pure 500 Ω
    Blend 500 Ω
    Desiccate 300 Ω
    Spray 500 Ω
    Working mode (Bipolar)
    Coag 100 Ω
    Main Material ABS external housing
    Main Frequency 512 kHz ± 5%
    High Frequency leakage
    Monopolar Less than 150 mA
    Monopolar Less than 150 mA
    Bipolar Less than 60 mA
    Low frequency leakage
    Normal polarity, Intact chassis ground Less than 50 μA
    Normal polarity, ground open Less than 50 μA
    Reverse polarity, ground open Less than 50 μA
    Sink current, 140V applied all inputs Less than 50 μA
    Packaging Dimensions (L x W X H) 34 x 16 x47 cm
    Gross Weight 8 Kg

  • Features

    • Output power is displayed digitally
      When the minimum or maximum power limit is achieved, a sound signal is generated
      Pure and Blend are two mono-polar cutting modes
      Spray and desiccate are two mono-polar coagulation modes
      Standard Coag is one bipolar mode
      Patient plate continuity monitoring circuits helps to protect the patients from electrical burns
      Isolated RF output
      Pencil or footswitch-controlled output
      Sound output volume controls
      Functions expandable for use in combination with endoscope or argon trolley
