Anesthesia Machine ZAM-A18 delivers gas supply, including O2, N2O, and Air. It provides a pipeline input range of 280 to 600 kPa and a Respiration Rate of 1 to 100 bpm (1 to 40 bpm under SIMV). With advanced ventilation modes and unmatched power and versatility, healthcare professionals can focus on what truly matters: the well-being of their patients. Our device is ideal for critical surgical settings or outpatient procedures. They ensure top-tier ventilation and monitoring and are tailored for adult and pediatric patients.
$4950
| Gas Supply | O2, N2O, Air |
| Pipeline Input Range | 280 to 600 kPa |
| Tidal Volume Range | 20 to 1500 mL |
| Pressure Range | 5 to 60 cmH2O |
| Respiration Rate | 1 to 100 bpm (1 to 40 bpm under SIMV) |
| Minute Volume Range | >18 L/min |
| I: E Range | 4:1 to 1:8 |
| Ventilation Modes |
Volume Control Ventilation (VCV) Synchronized Intermittent Mandatory Ventilation (SIMV) Assist/Control (A/C), Manual, and Stand-by modes |
| Flowmeter | 4 Tubes Cascade: 0 to 15 L/min for O2, N2O, and Air |
| CO2 Absorber & Vaporizer |
CO2 Absorber: 2L Vaporizer: 1 Selectatec, up to 2 mounts (Isoflurane, Sevoflurane, etc.) |
| Monitoring Features |
Monitors: VT, MV, Pmax, Pmean, Lung Compliance, Frequency Optional: FiO2, ETCO2 |
| Pre-Setting Functions |
Self-Test: Automatic Language Options: English, Chinese, etc. |
| Patient Range | Adult and Pediatric |
| Safety Features |
Hypoxic Guard System: N2O cut-off valve, O2 concentration >25% Safety Valve: <12.5 kPa O2 Flush: 25-75 L/min |
| Alarm Limits |
Audio/Visual Alerts: Tidal volume, MV, Paw, FiO2 Alerts for air failure, AC power failure, and low battery |
| LCD Display | 10.1-inch |
| Display Graphics | Waveforms of P-T, F-T, V-T |
| Casters | Front wheels with lock |
| Optional Features |
Auxiliary Common Gas Outlet (ACGO) Pin-Index Yoke System: Supports 11L O2, N2O cylinders |
| Battery Backup | ≥180 minutes |
| Power Supply | AC 110V-240V, 50Hz/60Hz |
| Dimensions | 70 × 85 × 140 cm |
| Weight | 65 kg |
Integrated breathing circuit
APL valve ensures excellent tightness
No need to replace drive bellows
High-precision vaporizer
10.1-inch screen for clear data display
Real-time detection for loops, Paw, BPM, VT, and compliance
Comprehensive monitoring of ventilation parameters
Comprehensive monitoring of preset parameters
Comprehensive monitoring of alarms
Comprehensive monitoring of breathing waveforms
Optional ACGO is available
Accessories | Quantity |
Anesthesia main unit with one vaporizer | 1 |
High-pressure O2 hose | 1 |
High-pressure N2O hose | 1 |
Mask | 1 |
Threaded pipe with “Y”- connector | 1 set |
Breathing bag | 1 |
Silicon screw tube φ22×400mm | 1 |
Tidal volume sampling tube (connect sampling signal transmission hose) | 1 |
Fuse RT1-20-1A | 2 |
Power line | 1 |
Operation manual | 1 |
Castor *4pcs/set | 1 |
Anesthesia Machine ZAM-A18 is used in ICUs, operating rooms, and anesthesiology departments for precise respiratory management and anesthesia delivery in adult, pediatric, and infant patients.
