ECG Machine ZECG-A10

ECG Machine ZECG-A10

ECG machine ZECG-A10 is a single channel electro cardiograph machine, with LCD display to set the parameters. System is incorporated with patient cable, main cable and thermal paper roll. Filter is added to improve the signal quality, ECG trace is printed on 50 mm paper further used to interpret the results.

Product Enquiry View Catalog
Channels Single channel
Paper size 50 mm × 2000 mm
Sampling frequency 800 Hz
EMG interference filter 35 Hz
Heart rate range 15 bpm to 350 bpm
Gain 2.5, 5.0, 10, 20, 40 mm/mV
Frequency response 0.05 Hz to 150 Hz
Input impedance ≥ 50 MΩ
Dimensions 315 × 215 × 77 mm
Weight 1.5 kg
  • Single channel
  • ECG traces printed on 50 mm paper
  • Maximum paper length 2 meter
  • Filter enhance signal quality
  • Power input form: AC/ DC and rechargeable Li-battery


Used in hospitals ICU, cardiology department to measure heart rate, detect the abnormal heart rhythms.
